UV-C ozone generators

A set ready to mounted on pipes corresponding to the diameters in and out of the UV ozonizer.
It comes with the by-pass valve and a pressure gauge for its proper regulation, 1 venturi injector, a static mixer, washable filter.

UV-C Ozone generator : Model

uv-c generate ozone

Ozone generator: UV-C Ozone 80W 1 lamp

Made of stainless steel
Delivered complete, mounted on a stainless steel frame, with an ozone injection pump, a regulation valve, a venturi injector, a static mixer, a pressure gauge, a cleanable filter, all mounted on pipes corresponding to the UV-C Ozonator inlet-outlet diameters. Remote electrical box from 1 lamp.

  • Number of UV lamps – 1
  • Dimension in cm – 8 x 16 x 51
  • Inlet / outlet fittings – 1″ (25 mm)
  • Ozone flow – 1 g / h
  • Electrical power of lamps, watts – 80 W
  • UV-C lamp power, watts – 25 W UV-C
  • Disinfection capacity – 13 m3 / h (30-50 millijoules / cm2)
uv-c generate ozone

Ozone generator: UV-C Ozone 160W 2 lamps

Made of stainless steel
Delivered complete, mounted on a stainless steel frame, with an ozone injection pump, a regulation valve, a venturi injector, a static mixer, a pressure gauge, a cleanable filter, all mounted on pipes corresponding to the UV-C Ozonator inlet-outlet diameters. Remote electrical box from 2 lamps.

  • Number of UV lamps – 2
  • Dimension in cm – 13 x 23 x 89
  • Inlet / outlet fittings – 1.5″ (38 mm)
  • Ozone flow – 2 g / h
  • Electrical power of lamps, watts – 160 W
  • UV-C lamp power, watts – 50 W UV-C
  • Disinfection capacity – 25 m3 / h (30-50 millijoules / cm2)
uv-c generate ozone

Ozone Generator: UV-C Ozone 240W 3 lamps

Made of stainless steel
Delivered complete, mounted on a stainless steel frame, with an ozone injection pump, a regulation valve, a venturi injector, a static mixer, a pressure gauge, a cleanable filter, all mounted on pipes corresponding to the UV-C Ozonator inlet-outlet diameters. Remote electrical box from 3 lamps.

  • Number of UV lamps – 3
  • Dimension in cm – 16 x 28 x 89
  • Inlet / outlet fittings – 1.5″ (38 mm)
  • Ozone flow – 3 g / h
  • Electrical power of lamps, watts – 240 W
  • UV-C lamp power, watts – 75 W UV-C
  • Disinfection capacity – 40 m3 / h (30-50 millijoules / cm2)
uv-c generate ozone

Ozone Generator: UV-C Ozone 320W 4 lamps

Made of stainless steel
Delivered complete, mounted on a stainless steel frame, with an ozone injection pump, a regulation valve, a venturi injector, a static mixer, a pressure gauge, a cleanable filter, all mounted on pipes corresponding to the UV-C Ozonator inlet-outlet diameters. Remote electrical box from 4 lamps.

  • Number of UV lamps – 4
  • Dimension in cm – 16 x 28 x 89
  • Inlet / outlet fittings – 2″ (50 mm)
  • Ozone flow – 4 g / h
  • Electrical power of lamps, watts – 320 W
  • UV-C power of lamps, watts – 100 W UV-C
  • Disinfection capacity – 54 m3 / h (30-50 millijoules / cm2)
uv-c generate ozone

Ozone Generator: UV-C Ozone 480W 6 lamps

Made of stainless steel
Delivered complete, mounted on a stainless steel frame, with an ozone injection pump, a regulation valve, a venturi injector, a static mixer, a pressure gauge, a cleanable filter, all mounted on pipes corresponding to the UV-C Ozonator inlet-outlet diameters. Remote electrical box from 6 lamps.

  • Number of UV lamps – 6
  • Dimension in cm – 18 x 33 x 89
  • Inlet / outlet fittings – 2.5″ (63 mm)
  • Ozone flow – 6 g / h
  • Electrical power of lamps, watts – 480 W
  • UV-C power of lamps, watts – 150 W UV-C
  • Disinfection capacity – 80 m3 / h (30-50 millijoules / cm2)
uv-c generate ozone

Ozone Generator: UV-C Ozone 640W 8 lamps

Made of stainless steel
Delivered complete, mounted on a stainless steel frame, with an ozone injection pump, a regulation valve, a venturi injector, a static mixer, a pressure gauge, a cleanable filter, all mounted on pipes corresponding to the UV-C Ozonator inlet-outlet diameters. Remote electrical box from 8 lamps.

  • Number of UV lamps – 8
  • Dimension in cm – 23 x 44 x 89
  • Inlet / outlet fittings – 2.5″ (63 mm)
  • Ozone flow – 8 g / h
  • Electrical power of lamps, watts – 640 W
  • UV-C lamp power, watts – 200 W UV-C
  • Disinfection capacity – 110 m3 / h (30-50 millijoules / cm2)
