UV stainless steel sterilizer

UV sterilizer model for swimming pool

UV-C sterilizer: UV 25W/1 lamp

Stainless steel UV-C water sterilizer complete kit (lamp, ballast, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 2 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 2 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 1 m3/h
• Number of UV lamp (s): 1
• Life time of lamps: 9,000 hrs.
• Capacity of lamps: 25 W
• Capacity of UV-C lamps: 7.8 W UV-C
• Water Input/Output: 1/2″
• Pressure bar: 3.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 0.8-2 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 1.6-4 m3
• Dimensions in cm: 6.2 × 7.5 x 58 cm

UV-C sterilizer: UV 55W/1 lamp

Stainless steel UV-C water sterilizer complete kit (lamp, ballast, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 6 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 6 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 3m3/h
• Number of UV lamp (s): 1
• Life time of lamps: 9,000 hrs.
• Capacity of lamps: 55 W
• Capacity of UV-C lamps: 17 W UV-C
• Water Input/Out: 3/4″
• Pressure bar: 3.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 2-6 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 4-12 m3
• Dimensions in cm: 6.2 × 7.5 x 94 cm

UV-C sterilizer:
UV 105W/ 1 lamp

Stainless steel UV-C water sterilizer complete kit (lamps, ballasts, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 9 m3/h
• Capacity of disinfection (30-50 mJ/cm2): 9 m3/h
• Capacity of disinfection (70-90 mJ/cm2): 4.5 m3/h
• Number of UV lamp (s): 1
• Life time of lamps: 13,000 hrs.
• Capacity of lamps: 105 W
• Capacity of UV-C lamps: 33 W UV-C
• Water Input/Output: 1″
• Pressure bar: 4.5 bar
• Volume of treated water for swimming pool /spa 12 hours/day : 6-12 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 12-25 m3
• Dimensions in cm: 13 x 23 x 89 cm

UV-C sterilizer: UV 210W/ 2 lamps

Stainless steel UV-C water sterilizer complete kit (lamps, ballasts, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 14 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 14 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 9 m3/h
• Number of UV lamp (s): 2
• Life time of lamps: 13,000 hrs.
• Capacity of lamps: 210 W
• Capacity of UV-C lamps: 65 W UV-C
• Water Input/Output: 1.5″
• Pressure bar: 4.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 13-23 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 26-46 m3
• Dimensions in cm: 13 x 23 x 89 cm

UV-C sterilizer: UV 315W/3 lamps

Stainless steel UV-C water sterilizer complete kit (lamps, ballasts, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 25 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 25 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 13.3 m3/h
• Number of UV lamps (s): 3
• Life time of lamps: 13,000 hrs.
• Capacity of lamps: 315 W
• Capacity of UV-C lamps: 100 W UV-C
• Water Input/Out put: 2″
• Pressure bar: 4.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 25-47 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 50-94 m3
• Dimensions in cm: 16 x 28 x 89 cm

UV-C sterilizer: UV 420W/4 lamps

Stainless steel UV-C water sterilizer complete kit (lamps, ballasts, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 40 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 40 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 18 m3/h
• Number of UV lamp (s): 4
• Life time of lamps: 13,000 hrs.
• Capacity of lamps: 420 W
• Capacity of UV-C lamps: 130 W UV-C
• Water Input/Output: 2.5″
• Pressure bar: 4.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 50-70 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 100-140 m3
• Dimensions in cm: 16 x 28 x 89 cm

UV-C sterilizer: UV 630W/6 lamps

Stainless steel UV-C water sterilizer complete kit (lamps, ballasts, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 60 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 60 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 26.6 m3/h
• Number of UV lamp (s): 6
• Life time of lamps: 13,000 hrs.
• Capacity of lamps: 630 W
• Capacity of UV-C lamps: 160 W UV-C
• Water Input/Output: Flange Mounted (Up on customer request)
• Pressure bar: 4.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 72-95 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 144-190 m3
• Dimensions in cm: 18 x 33 x 89 cm

UV-C sterilizer: UV 840W/8 lamps

Stainless steel UV-C water sterilizer complete kit (lamps, ballasts, electrical connection, quartz, joints etc.)

• Maximum pump flow (m3/hour): 80 m3/h
• Capacity of disinfection (30-50 mJ/cm2) : 80 m3/h
• Capacity of disinfection (70-90 mJ/cm2) : 36.6 m3/h
• Number of UV lamp (s): 8
• Life time of lamps: 13,000 hrs.
• Capacity of lamps: 840 W
• Capacity of UV-C lamps: 210 W UV-C
• Water Input/Output: Flange Mounted (Up on customer request)
• Pressure bar: 4.5 bar
• Volume of treated water for swimming pool/spa 12 hours/day : 96-120 m3
• Volume of treated water for swimming pool/spa 24 hours/day : 192-240 m3
• Dimensions in cm: 23 x 44 x 89 cm
